| Model | XR50D | XR100A | |
| Item | Parameter | Parameter | |
| Weights | Rating Payload（t） | 45 | 91 |
| Gross Weight（t） | 34 | 69 | |
| Dimension | Length（mm） | 8875 | 10820 |
| Width（mm） | 3965 | 5150 | |
| Height（mm） | 4245 | 4850 | |
| Engine | Model | Cummins QSX15-C | Cummins QST30 |
| Power（hp/kw） | 520 hp / 389kw | 1050 hp / 783 kw | |
| Transmission | Model | Allison 5620 ORS | Allison 8610 ORS |
| Ratios | Froward：4.00~0.67/ Reverse：1th5.12 2nd3.46 | Froward：4.24~0.73 / Reverse：5.75 | |
| No. of Speed（Froward/Reverse） | 6/2 | 6/1 | |
| Max. Speed（kw/h） | 65 | 47.6 | |
| Brakes | Type | Full hydraulic(front dry disc, rear oil cooled, mulitple disc) | Full hydraulic(front dry disc, rear oil cooled, mulitple disc) |
| Drive Axle | Type | Heavy duty axle with full floating semi axle shafts | Heavy duty axle with full floating semi axle shafts |
| Total Reduction Ratio | 17.83：1（Standard） | 29.70：1（Standard） | |
| 21.11：1（Optional） | 22.68：1（Optional） | ||
| Steering | Max. Type Steering Angle | 39 | 39 |
| Hoist | Lifting Time（s） | 13 | 16.3 |
| Lowering Time（s） | 9 | 18 | |
| Suspension | Type | Oil-nitrogen hybrid oil-gas suspension | Oil-nitrogen hybrid oil-gas suspension |
| Tyre | Model | 21.00-35 | 27.00-49 |
| Body | Leveling（m³） | 21.5 | 41.6 |
| 2:1Stacking（m³） | 27.5 | 57 | |
XEMACH / EQUIPMENT
REFERENCE IMAGE / CONFIGURATION MAY VARY
REFERENCE IMAGE / CONFIGURATION MAY VARYXEMACH / Dump Truck
Rigid Dump Truck · Small Size
| Engine | Cummins QSX15-C/QST30 |
| Power | 389-783kw |
| Payload | 45-91t |
Explore the available models and technical specifications below. We’ll help confirm the configuration, application and delivery scope for your project.
Email: info@xemach.com
WhatsApp: +1 669 292 4923
Choose the configuration
MODELS & SPECIFICATIONS.
Final specifications, equipment availability and commercial terms are confirmed in your written proposal.
See the equipment
PRODUCT VIDEOS.
A partner beyond the purchase
SUPPORT FOR
WHAT COMES NEXT.
Plan delivery, documentation and parts support around the equipment you select.
Our service processWhat should I include in my enquiry?
Equipment type, quantity, destination and working conditions. If you have a preferred model or attachment, include it so we can prepare a relevant quotation.
How do I arrange replacement parts?
Provide the machine serial number, component number and clear photographs. We confirm compatibility before preparing a parts proposal.
What warranty applies?
Coverage, exclusions, duration and service responsibilities are specified in your supply agreement. Contact us with the machine serial number and purchase reference.
