Original range specifications
Technical Specifications
| Description | Unit | LW300KN | ZL50GN |
|---|---|---|---|
| Rated operating load | kg | 3000 | 5000 |
| Bucket capacity | m³ | 1.5~2.5 | 2.5 ~ 4.5 |
| Machine weight | kg | 10900±200 | 17500 ± 300 |
| Dump clearance at maximum lift | mm | 2770~3260 | 3100 ~ 3780 |
| Reach at maximum lift | mm | 1010~1210 | 1100 ~ 1220 |
| Wheel base | mm | 2900 | 3300 |
| Tread | mm | 1850 | 2250 |
| Working height (fully lifted) | mm | 4870 | 5580 |
| Max. breakout force | kN | 130 | 175 ± 5 |
| Max. horse power | kW | 95 | 160 ± 5 |
| Hydraulic cycle time – raise | s | 5.4 | ≤ 6 |
| Total hydraulic cycle time | s | 9.3 | ≤ 10.5 |
| Min. turning radius over tyres | mm | 5170 | 5925 ± 50 |
| Articulation angle | ° | 38±1 | 38 |
| Gradeability | ° | 28 | 30 |
| Tyre size | mm | 17.5-25-12PR | 23.5-25-16PR |
| Overall machine dimension L×W×H | mm | 7245×2482×3320 | 8225 × 3016 × 3515 |
| Model | – | WP6G125E22 | WD10G220E21 |
| Emission standards | – | Emission 2 | Emission 2 |
| Rated Power/Speed | kW/rpm | 92/2200 | 162/2200 |
| Travel speed – I gear (F/R) | km/h | 12/16 | 13/17 |
| Travel speed – II gear (F/R) | km/h | 38/- | 41 |
| Optional | ZF Tranmission | ||
| ShangchaiSC11CB220G2B1 |
