| Model | XD360 | XD480 | XD680 |
| Engine | |||
| Engine Model | Rato R420 (or B&S) | Rato R740D (or B&S / KOOP) | Kubota D1105 (or Perkins) |
| Engine Type | Gasoline engine, single cylinder, air cooled | Gasoline engine, V-shaped double cylinders, air cooled | Diesel engine, three cylinders |
| Power | 15HP/3600rpm | 23HP/3600rpm | 18.2kw/3000rpm |
| Fuel Consumption | ≤1.2L/h | ≤2.7L/h | |
| Emissions | U.S. EPA Tier 4 and EU Stage V standards | U.S. EPA Tier 4 and EU Stage V standards | U.S. EPA Tier 4 and EU Stage V standards |
| Weight | |||
| Max. Lifting Weight | 300kg | 375kg | 1200kg |
| Operating weight | 700kg | 900kg | 1300kg |
| Rated Operating Weight | 200kg | 300kg | 450kg |
| Bucket | |||
| Capacity | 0.13m3 | 0.15m3 | 0.2m3 |
| Dimensions | |||
| Shipping Length | 2100mm | 2300mm | 2880mm |
| Shipping Width | 1050mm | 1150mm | 1200mm |
| Shipping Height | 1300mm | 1300mm | 1500mm |
| Starting Method | |||
| Starting Method | Electric | Electric | Electric |
| Gradability | |||
| Gradability | 30° | 30° | 30° |
| Travel System | |||
| Travel Speed | 0-5km/h | 0-6km/h | 0-6.5km/h |
| Hydraulic System | |||
| Hydraulic system | Local Brand | Local Brand | Italia PWG valve Denmark Danfoss |
| Refill Capacity | |||
| Hydraulic Oil Tank | 20L | 25L | 25L |
| Engine Oil Tank | 1.1L | 1.6L | 5.1L |
| Fuel Oil Tank | 6.7L | 25L | 35L |
XEMACH / EQUIPMENT
REFERENCE IMAGE / CONFIGURATION MAY VARY
REFERENCE IMAGE / CONFIGURATION MAY VARYXEMACH / Skid Steer Loaders
Skid Steer Loaders · Mini size
- Gasoline engine, diesel engine, EPA 4/ EU V
- Smaller size with big power, equals to 20 labors
Explore the available models and technical specifications below. We’ll help confirm the configuration, application and delivery scope for your project.
Email: info@xemach.com
WhatsApp: +1 669 292 4923
Choose the configuration
MODELS & SPECIFICATIONS.
Final specifications, equipment availability and commercial terms are confirmed in your written proposal.
See the equipment
PRODUCT VIDEOS.
A partner beyond the purchase
SUPPORT FOR
WHAT COMES NEXT.
Plan delivery, documentation and parts support around the equipment you select.
Our service processWhat should I include in my enquiry?
Equipment type, quantity, destination and working conditions. If you have a preferred model or attachment, include it so we can prepare a relevant quotation.
How do I arrange replacement parts?
Provide the machine serial number, component number and clear photographs. We confirm compatibility before preparing a parts proposal.
What warranty applies?
Coverage, exclusions, duration and service responsibilities are specified in your supply agreement. Contact us with the machine serial number and purchase reference.
