| 6×4 Dump Truck Specification Sheet | |
| DMS System | Foreign Trade No.: 2025-0009 |
| Vehicle Model | ND3260BD3J6Z31 |
| Sales Code | NG80-2638KZ 6×4-FK63 |
| Cab Position | Right-hand drive (RHD) |
| Wheelbase | 3800 + 1450 |
| Cab Type | NG80B short cab, flat roof |
| Operation Veight | Min.30ton |
| Heaped Volume | 20m3 |
| Engine | WP10.380E32 T2 |
| Transmission | 9JS150A + QH50 (spline) |
| Steering Gear | 8098 |
| Front Axle | 7.5 t |
| Drive Axle | 13 t BeiBen double-reduction axle / Final ratio 5.263 |
| Frame Section | 901-761; 317×70×8.5+7+8.5 (mm) |
| Dimension | 7700*2350*2800(mm) |
| Leaf Spring | 10 / 13 |
| Tires | 12.00R20, 18PR |
| Fuel Tank | 400 L, steel |
| Body | 5800×2300×1500; floor 10 mm, side 8 mm high-strength steel plate; rectangular box structure; floor with five longitudinal beams; domestic 180 hydraulic cylinder. |
| Standard Configuration | NG80B cab. Braking system: dual-circuit braking system, engine exhaust brake, automatic slack adjuster. Others: radiator guard, self-recovery towing hook, two-stage air filter, inter-axle differential lock, wheel differential lock, 135Ah battery, reverse buzzer, air horn, halogen tail lamps, mixed tread pattern. |
| Optional Configuration | ABS, desert air filter, headlamp guard, anti-collision bumper, LED tail lamps, 165Ah/180Ah battery. |
XEMACH / EQUIPMENT
REFERENCE IMAGE / CONFIGURATION MAY VARY
REFERENCE IMAGE / CONFIGURATION MAY VARYXEMACH / Dump Truck
On-highway Dump Truck
6×4 Dump Truck Specification Sheet DMS System Foreign Trade No.: 2025-0009 Vehicle Model ND3260BD3J6Z31 Sales Code NG80-2638KZ 6×4-FK63 Cab Position Right-hand drive (RHD) Wheelbase 3800 + 1450 Cab Type NG80B short cab, flat roof Operation Veight Min.30ton Heaped Volume 20m3 Engine WP10.380E32 T2 Transmission 9JS150A + QH50 (spline) Steering Gear 8098 Front Axle 7.5 t […]
