| Engine Model | Laidong380 |
| No. of Cylinders | 3 |
| Emissions | China National Tier 2 standards |
| Operating weight | 1500kg |
| Engine | |
| Engine Model | Laidong380 |
| No. of Cylinders | 3 |
| Power | 25HP |
| Emissions | China National Tier 2 standards |
| Weight | |
| Operating weight | 1500kg |
| Bucket | |
| Capacity | 0.03m3 |
| Width | 380mm |
| Dozer Blade | |
| Width | 1100mm |
| Height | 210mm |
| Travel System | |
| Max. Gradeability | 30° |
| Control Platform | |
| Control Platform | Pivot Control |
| Hydraulic System | |
| Hydraulic Valve | Shimadzu(Japan) |
| Operating Pressure | 16+3MPa |
| Pump Flow | 19+7L/min |
| Refill Capacity | |
| Hydraulic Oil Tank | 17L |
| Engine Oil Tank | 3.5L |
| Fuel Oil Tank | 22L |
| Dimensions | |
| Shipping Length | 2960mm |
| Shipping Width | 1100mm |
| Shipping Height | 2220mm |
| Track Type | Rubber with steel wire inside |
| Length to Center of Track | 920mm |
| Track Width | 180mm |
| Track Length | 1390mm |
| Ground Clearance | 400mm |
| Cooling System | |
| Cooling System | Water Cooled |
| Working Range | |
| Max. Digging Force | 8kN |
| Max. Reach at Ground Line | 3290mm |
| Max. Cutting Height | 3000mm |
| Max. Digging Depth | 1800mm |
| Max. Loading Height | 2060mm |
| Min. Front Swing Radius | 1260mm |
Notes:
All dimensions are approximate and may vary depending on bucket selection
