| Category | Unit | XT-02 | XT-04 | XT-06 | XT-08 | XT-10 |
| Length A | mm | 1032 | 1344 | 1723 | 2090 | 3210 |
| Max Open | mm | 420 | 600 | 750 | 860 | 1100 |
| Cutter Length | mm | 75 | 95 | 112 | 180 | 360 |
| Central Crushing Force | kn | 260 | 560 | 840 | 1170 | 1600 |
| Crushing Force | kn | 170 | 350 | 520 | 700 | 1000 |
| Working Pressure | bar | 24 | 24 | 31 | 31 | 32 |
| Oil Flow | lpm | 80-120 | 100-140 | 120-180 | 180-250 | 200-300 |
| Suitable Excavator | ton | 4-6 | 6-9 | 10-15 | 15-25 | 30-36 |
| Weight | kg | 310 | 510 | 1000 | 1700 | 2700 |
