| Technical Parameters |
XG833HG |
XG853HG |
XG866H |
XG876H |
| Basic |
Bucket Capacity |
1.7m3 |
2.7m3 |
4.2m3 |
5.2m3 |
| Rated Payload |
3000kg |
5000kg |
6500kg |
7000kg |
| Operating Weight |
10300(10500)±300kg |
16200±300kg |
21700±300kg |
24300±300kg |
| Traction Force |
97±3kN |
155±3kN |
180±3kN |
200±3kN |
| Breakout Force |
95±3kN |
155±3kN |
210±3kN |
245±3kN |
| L*W*H |
7450*2500*3180mm |
8180*3000*3400mm |
8860*3200*3540mm |
8890*3300*3460mm |
| Engine |
Model |
WeichaiP6G125E22 |
Weichai WP10G220E21 |
WeichaiWP10G240E341 |
WeichaiWP10G270E341 |
| Rated power |
92kW/2200rpm |
162KW/2200rpm |
178KW/2200rpm |
199KW/2200rpm |
| Max. Torque |
500N·m/1400-1600rpm |
860N·m/1400-1600rpm |
1200N·m/1400-1600rpm |
1100N·m/1400-1600rpm |
| Bore*Strple(mm) |
105*130mm |
126*130MM |
126*130mm |
126*130mm |
| No. of Cylinders/Displacement |
6/6.75L |
6/9.726L |
6/9.726L |
6/9.726L |
| Air Cleaner |
Three Stage Air Cleaner |
Three Stage Air Cleaner |
Three Stage Air Cleaner |
Three Stage Air Cleaner |
| Alternator |
70Amp |
70Amp |
70Amp |
70Amp |
| Bttery |
2-24v/105Ah |
2-24V/120Ah |
2-24V/120Ah |
2-24V/120Ah |
| Starting Motor |
24V/6kW |
24V/7.5kW |
24V/7.5kW |
24V/7.5kW |
| Drive Train |
Transmission Type |
Countershaft Powershift |
Planetary Powershift |
Planetary Powershift |
Countersaft Powershift |
| Shift Type |
Mechanical Powershift Control |
Mechanical Powershift Control |
Automtic electric propotional shift |
Automtic electric propotional shift |
| Pressure of Transmission |
1.1-1.5mpa |
1.1-1.5mpa |
1.1-1.5mpa |
1.2-1.5mpa |
| Torque Converter Type |
Single-stage&turbine, 3-element |
Single-stage, Duo-turbine, 4-element |
Single-stage&turbine, 3-element |
Single-stage, Duo turbine, 4-element |
| Axles |
Rigid(front)&Oscillating(Rear) |
Rigid(front)&Oscillating(Rear) |
Rigid(front)&Oscillating(Rear) |
Rigid(front)&Oscillating(Rear) |
| Rear Axle Oscillation |
±10 degree |
±6 degree |
±10 degree |
±10 degree |
| Differential |
Conventional |
Conventional |
Conventional |
Conventional |
| Main Reducer |
Spiral Bevel, 1-stage reduction |
Spiral Bevel, 1-stage Reduction |
Spiral Bevel, 1-stage Reduction |
Spiral Bevel, 1-stage Reduction |
| Final Reducer |
Palnetary Reduction |
Planetary Reduction |
Planetary Reduction |
Planetary Reduction |
| Tire |
17.5-35l-3 12 PR TT |
23.5-25 L-3 16PR TT |
26.5-25 L-3 24PR TT |
750/65R25**L-3TL |
| Travel Speed-forward |
1/12/24/36km/h |
11.5/36km/h |
6.5/12.8/24/38km/h |
6.7/13.2/24.6/36km/h |
| Travel speed-reverse |
8.5/28km/h |
16km/h |
639/13.5/25.6km/h |
7.1/13.9/24.9km/h |
| Brake System |
Service |
Single Circuit Caliper, dry brake |
Single Circuit Caliper, dry brake |
Single Circuit Caliper, dry brake |
Singl-line, Air push oil, Dry Brake |
| Settling |
0.7-0.78mpa |
0.7-0.78mpa |
0.7-0.78mpa |
0.7-0.78mpa |
| Parking |
Flexible Shaft Controlled Caliper Brake |
Flexible Shaft Controlled Caliper Brake |
Pneumatic drum brake |
Pneumatic drum brake |
| Emergency |
Pneumatic drum brake |
Pneumatic drum brake |
| Steering System |
Type |
Hydraulic Load Sensing System |
Hydraulic Load Sensing System |
Hydraulic Load Sensing System |
Flow Amplitication Steering |
| Pump |
246L/min 2200rpm |
152L/min 2200rpm |
186L/min 2200rpm |
207L/min 2200rpm |
| Systeme Presure |
14mpa |
15MPa |
16MPa |
18MPa |
| Cylinder Type |
Double Acting |
Double Acting |
Double Acting |
Double Acting |
| Steering Angle |
±35° |
±35° |
±35° |
±35° |
| Hydraulic System |
Type |
Joystick Control |
Joystick Control |
Joystick Control |
onstactn Variabl Double Pump Contluence |
| Pump |
246L/min 2200rpm |
190L/min 2200rpm |
232L/min 2200rpm |
232L/min 2200rpm |
| System Pressure |
16MPa |
18MPa |
19MPa |
23MPa |
| Cycle time(sec) |
9 |
11.5 |
≤10.8 |
≤10.5 |
| Service Refill Capacity |
Fuel Tank(L) |
200L |
285L |
330L |
350L |
| Hydraulic Tank(L) |
165/170(3RD spool)L |
265L |
270L |
280L |
| Crankshaft(L) |
14L |
30L |
19L |
19L(CH-4) |
| Transmission(L) |
36L |
45L |
43L(CH-4) |
46L(CH-4) |
| Front Axle/Rear Axle(L) |
18/18L |
28/28L |
31/31L |
46/46L |
