| Parameter of Backhoe Loader XEM80 |
| Operating Weight |
| Overall Operating Weight |
8000KG |
| Transport Dimension |
| L*W*H |
7600×2260×2890mm |
| Wheel base |
2250mm |
| Min. Ground Clearance |
300mm |
| Bucket Capacity |
1.3m3 |
| Breakout Force |
38KN |
| Loading Lifting Capacity |
2800KG |
| Bucket Dumping Height |
2800mm |
| Bucket Dumping Distance |
1062mm |
| Digging Depth |
52mm |
| Backhoe Capacity（Width） |
0.35m3(620mm) |
| Max. Digging Depth |
4100mm |
| Optional Digging Depth |
5000mm |
| Swing Angle of backhoe |
190o |
| Max. Pulling Force |
39KN |
| Engine |
| Model |
Cummins 4BTA3.9-C100 |
| Type |
In Line，Direct injection，Four-Stroke，Water Cooling |
| Rated Power |
80KW |
| Steering System |
| Steering Angle |
±36 o |
| Min. turning radius |
6581mm |
| Pressure of the system |
12Mpa |
| Axle |
| Main Transmission Type |
Double Reduction |
| Final Reducer |
Single Stage Final Reducer |
| 4/18.5t |
| Rated Loader of Axle |
|
| Transmission System |
| Torque Converter |
| Model |
YJ280 |
| Type |
Single-stage Three Elements |
| Cooling Method |
Oil-cooling Pressure Circulation |
| Gearbox |
| Type |
Fixed Shaft Power Transmission |
| Gears |
Two Gears Ahead, Two Gears Astern |
| Max.Speed |
30Km/h |
| Tyre |
| Model |
（F）14-17.5 |
| （R）19.5L-24 |
| Pressure of Front wheel |
0.22 Mpa |
| Pressure of Back Wheel |
0.22 Mpa |
| Brake System |
| Service Brake |
Air Over Oil Caliper Brake |
| External Type |
| Self-regulation |
| Self-balance |
| Emergency Brake |
Operation Power Implementing brake |
| Manual Operation Power Terminating Brake |
| Hydraulic System |
| Pressure of Hydraulic System |
22Mpa |
| Digging Power of Excavator Grab |
46.5KN |
| Digging Power of Dipper |
31KN |
| Bucket Lifting Time |
5.4S |
| Bucket Lowering Time |
3.1S |
| Bucket Discharge Time |
2.0S |
| The parameters or configuration are subject to change without notice. |
